Torp TM50 Motor Upgrade For Sur-Ron Ultra Bee
Regular price
$1,850.00
Sale price
$1,850.00
Regular price
Shipping calculated at checkout.
Out of stock
Upgrade your Sur-Ron Ultra Bee with the durable Torp TM50 Motor or TM50 Pro, meticulously designed by expert engineers with top-quality components. Experience exceptional speed and heat efficiency on even the most challenging terrain, with up to 58kW of power output (TM50 Pro).
Featuring low resistance, precise control, and smooth operating, the encoder-based Torp TM50 motor is the leading aftermarket power upgrade for Sur-Ron Ultra Bee. Choose from the TM50 (Off-Road, High Torque) or TM50 Pro (Higher Top Speed) versions for the ultimate Sur-Ron motor upgrade.
Torp TM50 Motor / TM50 Pro Features
- Unparalleled Power: Most powerful Sur-Ron Ultra Bee motor with the lowest resistance on the market
- DYNO Test: 52kW/58kW Peak Power | 1100A/1200A Phase Current | 98.5Nm/102Nm Max Torque
- Max Performance: improved motor power and performance without the risk of overheating
- Lowest Resistance: built with thick motor windings for low resistance
- Precision Control: encoder position sensor utilized for precise control and seamless operation at both high and low speeds
- Compatibility: Encoder (default) or Hall Position Sensors available for a wide range of compatibility with superb precision especially when paired with Torp Controllers (encoder), even at high speeds
- Durability & Longevity: constructed from top-quality materials for durability and a longer life span
- Designed and developed in the EU for Sur-Ron Ultra Bee with adaptable mounting options for other electric motorbikes
Torp TM50 Motor / TM50 Pro Specs
| Torp TM50 Motor | Torp TM50 Pro Motor | |
| Peak Power: | 52 kW | 58 kW |
| Continuous Power: | 22 kW | 24 kW |
| Max Phase Current: | 1100 A | 1200 A |
| Max Torque: | 98.5 Nm | 102 Nm |
| Torque 500 A: | 52.5 Nm | 49 Nm |
| KV Rating: | 85 | 88 |
| Motor Resistance: | 2.3 mΩ | 2 mΩ |
| Phase Cross-Section: | 36 mm² | 42 mm² |
| Magnet Length: | 75 mm | 80 mm |
| Weight: | 30.2 lbs (13.7 kg) | 31.3 lbs (14.2 kg) |
| Motor Size: | 6.7"×7.8" (170×198 mm) | 6.7"×7.8" (170×198 mm) |
Additional Specifications
- Motor Type: IPM
- Max RPM: 10,000 RPM
- Position Sensor: Encoder (default) / Hall (optional)
- Encoder Points: 1024 (4096)
- Max Magnet Temp.: 150 °C
- Temperature Sensor: PT1000
- Efficiency: up to 95%
- Protection Class: IP67
- Terminal Lug Size: M6 50 mm²
- Installation: Mid
- Pole Pairs: 5
- Cooling Method: Air
